RF Component Testing with a USB Vector Network Analyzer

Using a Vector Network Analyzer (VNA) for RF component testing for design and manufacturing is based on how the component performs. The analyzer is used in multiple ways from design to manufacturing to tuning, field monitoring and maintenance of antennas, filters, mixers, amplifiers, circulators, isolators, and other RF components. Key considerations component designers should pay attention to when finding an analyzer that fits their needs is a great dynamic range, and fast measurement speed.



Copper Mountain Technologies offers affordable, high-performance VNA solutions with NIST traceable metrology-grade accuracy for RF component testing for manufacturers and designers with 130 dB – 152 dB dynamic range, and fast measurement speed to provide accurate testing results. We also have many resources for antenna design available on our Resources for IoT Designers page.

Key Considerations:

Dynamic Range

CMT Vector Network Analyzers have industry-leading dynamic range and sweep speed. These VNA solutions feature a large frequency range with options for frequency scan segmentation. This allows for optimal use of the device to realize the maximum dynamic range while maintaining high measurement speed, which is ideal for RF component testing.

Measurement Speed

A fast measurement speed is especially important in production environments when you need to do RF component testing quickly on the line. Copper Mountain Technologies VNAs have many models with fast measurement speed, like the Advanced Series with as low as 12 microseconds per point. CMT’s Manufacturing Test software enables automated manufacturing capabilities that streamline production test processes to quickly deliver accurate and repeatable measurement results

Automatically Remove Fixture Effects
component image with NIC logo (centered)
Longtime Users Remain Bullish on Price/Performance Combination of CMT Analyzers
Passive RF System Measurements rf component testing
Testing an Amplifier with a 2-Port VNA
J2102B Copper Mountain rf component testing
Power Integrity Measurements
testing and matching pcb antennas testing rf components
Testing and Matching PCB Antennas
using a vna with a portable battery
Using USB VNAs with an Off-the-shelf Battery
RF mixer characterization testing rf components
RF Mixer Characterization
measurement of high powered devices rf component testing
Measurement of High Power Devices
in circuit antenna verification rf component testing
In-Circuit Antenna Verification
Synmatrix Logo
SynMatrix Integration for Filter Design and Production Test and Tuning
automated antenna testing rf component testing
Automated Antenna Testing
Spectral Analysis with a USB Vector Network Analyzer (VNA) testing rf components
Spectral Analysis with a Vector Network Analyzer

Advanced VNAs for RF Component Testing

High-performance 2-port VNAs up to 22 GHz suitable for advanced applications like research and design, automotive and defense radar development, satellite communications, and high-speed digital systems. Our Advanced Series vector network analyzers deliver industry-leading dynamic range and sweep speed, with all the features engineers have come to expect included standard in our software.

  • Direct receiver access and frequency extension compatible options.
  • Ultra-fast sweep speed as low as 12 µs/point.
  • 130 dB dynamic range.
  • A2202-DFx model features both DRA and Frequency Extension compatibility.
  • Reliable measurements up to 330 GHz with use of a compatible frequency extender.
  • No onboard computer, avoiding software obsolescence for reliable long-term use.
  • License-free software included with purchase.
  • Manufacturing Test software plug-in available for integration into production test systems.

A2202-Fx 2-Port 22 GHz Frequency Extension Compatible Vector Network Analyzer

100 kHz – 22 GHz

  • 133 dB Dynamic Range
  • 12 µs/point Measurement Speed
  • Compatible with ANY frequency extender

A2202-DFx 2-Port 22 GHz Direct Receiver Access and Frequency Extender Compatible Vector Network Analyzer

100 kHz – 22 GHz

  • 133 dB Dynamic Range
  • 12 µs/point Measurement Speed
  • Compatible with ANY frequency extender
  • Direct Receiver Access

New

BFx-02 Frequency Extension Base for S-Parameters Measurement

4 GHz – 20 GHz

  • Frequency range: 4 to 20 GHz
  • RF output power: up to +20 dBm
  • LO output power: up to +20 dBm
  • Weight: 4.4Kg

Related Products:

SC0402-Filter-Measurement-Transparent-Web (1)

Select Series VNAs up to 18 GHz

Select Series VNAs have a dynamic range up to 140 dB which allows them to maintain a wide measurement range at high measurement speeds.

A2202-DFx Advanced Series 2-Port 22 GHz Vector Network Analyzer for Direct Receiver Access and Frequency Extender Compatible

Advanced Series VNAs up to 22 GHz

Advanced Series VNAs have up to 133 dB dynamic range which allows them to maintain a wide measurement range at high measurement speeds. Frequency Extension compatible models are available.

If you’re interested in learning more about how our USB VNAs can be used for RF component testing or to determine which instrument is most suitable to your unique application, ask an engineer!
