Brian Walker

VNA Measurement Techniques for Antenna Test

A Copper Mountain Technologies' VNA can make antenna measurements easy. If a pair of antennas must be measured at close range, a simple 2-port measurement can be made. For the evaluation of antenna patterns, a reference antenna can be utilized to normalize the illuminating signal. Various methods of antenna measurement, from simple to sophisticated will be examined and explained. A field pattern measurement of an antenna using a rotating platform will be demonstrated.
Tabletop Materials Measurements
John Schultz at Compass Technology Group

New Developments in Microwave Materials Measurements

Fundamental to microwave device design is knowing the electromagnetic performance of materials used in the device. Whether it is a microwave substrate, an antenna radome, or an electromagnetic inference absorber, methods are needed to evaluate materials and determine their intrinsic dielectric and magnetic properties. Designers use these intrinsic parameters (permittivity and permeability) to develop or optimize microwave and RF components. Measuring the performance of microwave materials requires a system that includes i) a measurement fixture and ii) a microwave analyzer. The fixture and the analyzer are usually connected with microwave or radio frequency (RF) cables.

On-Demand Webinar

Placeholder
Subbaiah Pemmaiah

Basics of a VNA

In this webinar, we will look at the basics of a Vector Network Analyzer, its architecture, and some of its applications. The webinar will be concluded with a VNA demo by Subbaiah.
VNA Basics Screenshot
Brian Walker

VNA Basics

This webinar will touch on the basic concepts which underlay the operation of a Vector Network Analyzer. What does it really measure? What are the key components? What are its limitations? How does one compare one analyzer to another? What are the key specifications? We’ll take a brief look at the evolution of VNA design over the years to understand how a state-of-the-art VNA is USB based without an embedded operating system. The viewer should come away with an intuitive understanding of VNA operation and how best to use this important measurement tool
Placeholder
Brian Walker

Offset Frequency Measurements with a VNA

A Copper Mountain Technologies VNA can make offset measurements where the stimulus and receiver are not at the same frequencies. This allows for the characterization of upconverters, downconverters, and mixers. Because the frequencies differ, phase measurement has no meaning and only scalar amplitude is determined. Vector mixer calibration utilizing a de-embedded reference mixer makes the stimulus and receiver measurements the same and allows for full amplitude and phase characterization of the mixer under test. De-embedding of the reference mixer requires a second-tier calibration. In this webinar, both of these methods will be demonstrated.


On-Demand Webinar

Brian Walker

VNA Master Class: VNA Tests for 5G Automotive Applications

For automotive systems, the inclusion of mmWave radar along with other RF systems and high current DC switching for electric vehicles present numerous challenges for the automotive designer. This webinar will introduce a few of these challenges and highlight measurement solutions.

On-Demand Webinar

Brian Walker

VNA Master Class: VNA Tests for 5G Automotive Applications

vna master class: webinar series

On-Demand Webinar

Brian Walker

Effects of Random Factors on the Metrology of VNA Measurement

Cobalt USB Vector Network Analyzer C1209 2-Port VNA and Automated Calibration Module ACM2509
Subbaiah Pemmaiah

Software Tips and Tricks (Measuring Impedance, Calibration, Time Domain Measurements)

The Copper Mountain Technologies vector network analyzer software has a lot of features and capabilities. During this session, we will review some aspects of the software in more detail to help users understand how to get the most out of the software.
