Simplify Filter Design and Production Test and Tuning

SynMatrix Technologies Inc. was founded in 2018 and is a Toronto-based software company that develops automation technology and test measurement tools for the RF component design community. SynMatrix’s mission is to provide a single platform that can help significantly reduce the time to engineer and manufacture RF filters. The company is striving to build one of the most comprehensive and powerful platforms for RF component design that support 5G and mmWave application requirements.



SynMatrix currently features several functions that cover synthesis, optimization, filter diagnostics, real-time test and tuning, and manufacturing workflow management.



SynMatrix has developed workflow integration with Copper Mountain Technologies’ VNAs that enables engineers to use the SynMatrix software with fast, affordable CMT vector network analyzers.

A Single Platform to Help Reduce R&D Cycle Time

Automatic workflow intergation with Ansys HFSS

Automatic 3D modelling and an automatic AI optimization workflow integrated with Ansys HFSS.

Real-time tuning with VNA integration



Simplified test tuning workflow that offers users a simple GUI that helps guide the tuning process for junior techs.

Designed for filter manufacturing and quality control

Computer-aided manufacturing workflow system can be used for data traceability, managing project orders, and maintaining quality.



Faster debug and tech training


Import a S2P file from a network analyzer or EM software and diagnose issues, fast. Comprehensive features for debugging, reworking, and tuning tech training.

Design Support for Many Filter Types

Bandpass Filter
Bandstop Filter
Lowpass Filter
Multiband Filter

VNAs Compatible with SynMatrix Filter Testing and Tuning Software


S5243 2-Port 44 GHz Analyzer

10 MHz – 44 GHz


M5045 2-Port 4.5 GHz Analyzer

300 kHz – 4.5 GHz


M5065 2-Port 6.5 GHz Analyzer

300 kHz – 6.5 GHz


M5090 2-Port 8.5 GHz Analyzer

300 kHz – 8.5 GHz


M5180 2-Port 18 GHz Analyzer

300 kHz – 18 GHz

End Of Sale

S5045 2-Port 4.5 GHz Analyzer

9 kHz – 4.5 GHz

End Of Sale

S5065 2-Port 6.5 GHz Analyzer

9 kHz – 6.5 GHz

End Of Sale

S5085 2-Port 8.5 GHz Analyzer

9 kHz – 8.5 GHz


S5180B 2-Port 18 GHz Analyzer

100 kHz – 18 GHz

Available Stock

SC5065 2-Port 6.5 GHz Analyzer

300 kHz – 6.5 GHz

Available Stock

SC5090 2-Port 9 GHz Analyzer

300 kHz – 9 GHz

Available Stock

C1209 2-Port 9 GHz Analyzer

100 kHz – 9 GHz

Available Stock

C2209 2-Port 9 GHz Analyzer, Direct Receiver Access

100 kHz – 9 GHz

Available Stock

C4209 2-Port 9 GHz Analyzer, Frequency Extension Compatible

100 kHz – 9 GHz


C1220 2-Port 20 GHz Analyzer

100 kHz – 20 GHz


C2220 2-Port 20 GHz Analyzer, Direct Receiver Access

100 kHz – 20 GHz

Available Stock

C4220 2-Port 20 GHz Analyzer, Frequency Extension Compatible

100 kHz – 20 GHz

Available Stock

C1409 4-Port 9 GHz Analyzer

100 kHz – 9 GHz

Available Stock

C2409 4-Port 9 GHz Analyzer, Direct Receiver Access

100 kHz – 9 GHz


C4409 4-Port 9 GHz Analyzer, Frequency Extension Compatible

100 kHz – 9 GHz

Available Stock

C1420 4-Port 20 GHz Analyzer

100 kHz – 20 GHz


C2420 4-Port 20 GHz Analyzer, Direct Receiver Access

100 kHz – 20 GHz


C4420 4-Port 20 GHz Analyzer, Frequency Extension Compatible

100 kHz – 20 GHz
