Copper Mountain Technologies and Maury Microwave

S-Parameter Measurements with Uncertainty



S-Parameter Uncertainty Measurements with Copper Mountain Technologies and Maury MicrowaveAs new technologies emerge and are introduced as standards, the specifications and requirements for products get tighter, and the competitive landscape even fiercer.  This puts the responsibility on engineers and designers to squeeze out every tenth of a dB of performance, and to publish ambitious specifications.  This introduces a potential problem; how can one balance the desire to list aggressive specifications yet still have confidence that their products will meet the promised performance?  And not only performance as measured by the designer but also by the end-user, today and over time.
Scientists have been investigating the sources of uncertainty in microwave and RF measurements and have proposed models and techniques to quantify the individual contributions.   These contributions can be systematically determined and added as part of an overall S-parameters measurement.
Maury Microwave’s Insight VNA calibration and S-parameter measurement software can be used with almost any Copper Mountain Technologies 2-port or 4-port VNA to calibrate, validate and measure S-parameters with uncertainty.  Individual uncertainty contributors such as the VNA, calibration kit, cable assemblies, connectors, and operator are quantified and shown real-time with the S-parameter measurements. Copper Mountain Technologies’ VNAs offer some of the industry’s best-in-class uncertainty and result in more accurate S-parameter measurements. This empowers a designer to report a product’s performance with uncertainties, and give both designers and end-users the confidence needed to ensure product performance over time.

Copper Mountain Technologies’ VNAs compatible with Maury Microwave S-Parameter Measurements with Uncertainty Solutions include:




TR1300/1 2-Port 1.3 GHz Analyzer

300 kHz - 1.3 GHz


TR5048 2-Port 4.8 GHz Analyzer

20 kHz - 4.8 GHz


TR7530 2-Port 75 Ohm 3.0 GHz Analyzer

1000

20 kHz - 3 GHz


M5065 2-Port 6.5 GHz Analyzer

300 kHz - 6.5 GHz



M5090 2-Port 8.5 GHz Analyzer

300 kHz - 8.5 GHz


M5180 2-Port 18 GHz Analyzer

300 kHz - 18 GHz


S5048 2-Port 4.8 GHz Analyzer

20 kHz - 4.8 GHz


S5065 2-Port 6.5 GHz Analyzer

9 kHz - 6.5 GHz



S5085 2-Port 8.5 GHz Analyzer

9 kHz - 8.5 GHz


S5180 2-Port 18 GHz Analyzer

100 kHz - 18 GHz


S7530 2-Port 75 Ohm 3.0 GHz Analyzer

2000

20 kHz - 3 GHz


SC5065 2-Port 6.5 GHz Analyzer

300 kHz - 6.5 GHz



SC5090 2-Port 9 GHz Analyzer

300 kHz - 9 GHz


C1209 2-Port 9 GHz Analyzer

100 kHz - 9 GHz


C2209 2-Port 9 GHz Analyzer, Direct Receiver Access

100 kHz - 9 GHz


C1409 4-Port 9 GHz Analyzer

100 kHz - 9 GHz



C2409 4-Port 9 GHz Analyzer, Direct Receiver Access

100 kHz - 9 GHz


C1220 2-Port 20 GHz Analyzer

100 kHz - 20 GHz


C1420 4-Port 20 GHz Analyzer

100 kHz - 20 GHz


C2220 2-Port 20 GHz Analyzer, Direct Receiver Access

100 kHz - 20 GHz



C2420 4-Port 20 GHz Analyzer, Direct Receiver Access

100 kHz - 20 GHz


Planar 304/1 3.2 GHz Analyzer

100 kHz - 3.2 GHz


Planar 804/1 8 GHz Analyzer

100 kHz - 8 GHz


Planar 808/1 8 GHz Analyzer

100 kHz - 8 GHz
