Antenna Design and Measurement Software

antenna tuning antune softwareAnTune software assists in designing antennas and RF impedance networks. Their software runs on PC/Windows and can communicate with a Vector Network Analyzer over GPIB/USB/LAN for automatic design optimizing. AnTune measurement software delivers live optimized network matching results based on data live feed from a VNA or by importing S-parameters from a file. The main focus of the software is to improve embedded antennas and SMD RF filter performance.
AnTune software supports VNAs from Copper Mountain Technologies. The combo of CMT VNAs and the AnTune software is an effective solution for all kinds of RF impedance-related design work as it gives a high data rate.







Copper Mountain Technologies’ VNAs compatible with AnTune’s Antenna Design software:




R60 1-Port 6 GHz Analyzer

1 MHz - 6 GHz


R140 1-Port 14 GHz Analyzer

85 MHz - 14 GHz


R180 1-Port 18 GHz Analyzer

1 MHz - 18 GHz


M5065 2-Port 6.5 GHz Analyzer

300 kHz - 6.5 GHz


M5090 2-Port 8.5 GHz Analyzer

300 kHz - 8.5 GHz


M5180 2-Port 18 GHz Analyzer

300 kHz - 18 GHz


TR1300/1 2-Port 1.3 GHz Analyzer

300 kHz - 1.3 GHz


TR5048 2-Port 4.8 GHz Analyzer

20 kHz - 4.8 GHz


TR7530 2-Port 75 Ohm 3.0 GHz Analyzer

1000

20 kHz - 3 GHz


S5048 2-Port 4.8 GHz Analyzer

20 kHz - 4.8 GHz


S5065 2-Port 6.5 GHz Analyzer

9 kHz - 6.5 GHz


S5085 2-Port 8.5 GHz Analyzer

9 kHz - 8.5 GHz


S5180 2-Port 18 GHz Analyzer

100 kHz - 18 GHz


S7530 2-Port 75 Ohm 3.0 GHz Analyzer

2000

20 kHz - 3 GHz


C1209 2-Port 9 GHz Analyzer

100 kHz - 9 GHz


C2209 2-Port 9 GHz Analyzer, Direct Receiver Access

100 kHz - 9 GHz


C4209 2-Port 9 GHz Analyzer, Frequency Extension Compatible

100 kHz - 9 GHz


C1409 4-Port 9 GHz Analyzer

100 kHz - 9 GHz


C2409 4-Port 9 GHz Analyzer, Direct Receiver Access

100 kHz - 9 GHz


C4409 4-Port 9 GHz Analyzer, Frequency Extension Compatible

100 kHz - 9 GHz


C1220 2-Port 20 GHz Analyzer

100 kHz - 20 GHz


C1420 4-Port 20 GHz Analyzer

100 kHz - 20 GHz


C2220 2-Port 20 GHz Analyzer, Direct Receiver Access

100 kHz - 20 GHz


C4220 2-Port 20 GHz Analyzer, Frequency Extension Compatible

100 kHz - 20 GHz


C2420 4-Port 20 GHz Analyzer, Direct Receiver Access

100 kHz - 20 GHz


C4420 4-Port 20 GHz Analyzer, Frequency Extension Compatible

100 kHz - 20 GHz



Learn more about AnTune.
