WR3.4 Frequency Extension Solution, 220-330 GHz with VDI Extender Modules
CobaltFx cost-effective millimeter wave frequency extension system allows you to build a scalable and affordable 5G testing solution.
- Frequency Range: 90-140 GHz
- Connector Type: Waveguide WR8.0
Recommended VNAs
The total cost of the system depends on the selected VNA. The extenders are packaged in small and versatile enclosures that allow for flexible port arrangements. VDI extenders can be purchased from CMT or VDI.
- - Frequency range: 220 GHz
- - Effective Directivity: 30dB
- - Dynamic range: 115 dB
- - Impedance: 50 Ohm
The system can be used for a variety of applications including antenna range measurements, material characterization, wafer s-parameter measurements, automotive radar & sensor testing, etc.
If you want to consult with our engineers about your specific application, please Ask an Engineer.
Every CMT VNA includes an RF measurement module and software application which runs on a Windows PC, laptop, or tablet, connecting to the measurement hardware via USB interface. Software can be installed on multiple computers that share the use of the analyzer measurement module. Test Automation programming in LabView, Python, MATLAB, .NET, etc.
Datasheets
Advanced Series Specification Sheet
Manuals
S2 & S4 Programming Manual (COM) | S2 & S4 Programming Manual (SCPI) | S2 Operating Manual | S4 Operating Manual | Booster Operating Manual
Software
S2 VNA Software | S2 Software Release Notes | S4 VNA Software | S4 Software Release Notes | Software/Documentation Page
Testing Automation
Programming Examples | Programming Guides | SX LABView Drivers
