Matching Circuit Design

Optenni Ltd. develops the leading professional matching circuit synthesis and optimization software Optenni Lab™ for solving all matching problems in the RF chain within wireless devices. Optenni Lab can optimize broadband, multiband, multiport, and tunable matching circuits for antennas, filters, amplifiers, switches, tuners, and other RF components.



Optenni Lab can be easily interfaced with network analyzers to read measured impedance data from network analyzers and to optimize matching circuits in real-time based on the changing measurement data.



Optenni Lab supports LAN, USB, and GPIB connections to network analyzers. The setting up of the link to network analyzers is extremely simple. When the measurement has been set up, you can examine how the bandwidth potential or electromagnetic isolation changes when the antenna configuration is changed. You can see how the performance through a matching circuit changes and re-optimize the matching circuit as the antenna is changed. These features greatly enhance the productivity of antenna prototyping and measurement activities.



RF designers use Optenni Lab for a wide variety of applications, ranging from antenna matching to NFC system optimization, from multiplexer design to LNA matching. Optenni Lab is commonly used in the design of e.g. the following products:



    • Portable wireless devices, such as mobile phones, tablets, computers, and cameras
    • Base station antennas and WLAN routers
    • Car communication systems, access keys, and tire pressure monitors
    • Medical equipment, such as hearing aids, MRI scanners, and portable patient monitors



Copper Mountain Technologies’ VNAs compatible with Optenni software:



Available Stock

R60 1-Port 6 GHz Analyzer

1 MHz - 6 GHz

Available Stock

R140B 1-Port 14 GHz Analyzer

85 MHz - 14 GHz

Available Stock

R180 1-Port 18 GHz Analyzer

1 MHz - 18 GHz


M5065 2-Port 6.5 GHz Analyzer

300 kHz - 6.5 GHz


M5090 2-Port 8.5 GHz Analyzer

300 kHz - 8.5 GHz


M5180 2-Port 18 GHz Analyzer

300 kHz - 18 GHz

Available Stock

TR1300/1 2-Port 1.3 GHz Analyzer

300 kHz - 1.3 GHz


S5045 2-Port 4.5 GHz Analyzer

9 kHz - 4.5 GHz


S5065 2-Port 6.5 GHz Analyzer

9 kHz - 6.5 GHz


S5085 2-Port 8.5 GHz Analyzer

9 kHz - 8.5 GHz


S5180B 2-Port 18 GHz Analyzer

100 kHz - 18 GHz


S5243 2-Port 44 GHz Analyzer

10 MHz - 44 GHz

Available Stock

C1209 2-Port 9 GHz Analyzer

100 kHz - 9 GHz

Available Stock

C2209 2-Port 9 GHz Analyzer, Direct Receiver Access

100 kHz - 9 GHz

Available Stock

C4209 2-Port 9 GHz Analyzer, Frequency Extension Compatible

100 kHz - 9 GHz

Available Stock

C1409 4-Port 9 GHz Analyzer

100 kHz - 9 GHz

Available Stock

C2409 4-Port 9 GHz Analyzer, Direct Receiver Access

100 kHz - 9 GHz


C4409 4-Port 9 GHz Analyzer, Frequency Extension Compatible

100 kHz - 9 GHz


C1220 2-Port 20 GHz Analyzer

100 kHz - 20 GHz

Available Stock

C1420 4-Port 20 GHz Analyzer

100 kHz - 20 GHz


C2220 2-Port 20 GHz Analyzer, Direct Receiver Access

100 kHz - 20 GHz

Available Stock

C4220 2-Port 20 GHz Analyzer, Frequency Extension Compatible

100 kHz - 20 GHz


C2420 4-Port 20 GHz Analyzer, Direct Receiver Access

100 kHz - 20 GHz


C4420 4-Port 20 GHz Analyzer, Frequency Extension Compatible

100 kHz - 20 GHz



Learn more about Optenni.
